DMW
Centrifuges are the heavy duty Centrifuge with robust
construction, provide rapid acceleration and smooth
running. We at ‘DMW’ have experienced and qualified
team of Engineers, which continuously make changes according
to the latest technology, and customer needs to ensure
customers satisfaction. Our machines consume less starting
and running current and have powerful efficient braking.
BASKET
The perforated basket is made of Stainless Steel (AISI
304/316) in standard sizes and in different gauges according
to the size of the machine. The basket is dynamically
balanced for vibration free running. The outer cage
sidewalls are also made of stainless steel AISI 304/316.
BEARING
HOUSING & SHAFT
Bearing Housing is of CI and main shaft is of Alloy
Steel and is precisely machined to withstand the loads
caused by the centrifugal force. The 3 nos. bearings
supporting the main shaft are heavy duty roller and
thrust bearings.
DRIVE
SYSTEM
The revolving cage is driven by vertical T.E.F.C. Motor
fitted with Fluid Coupling for progressive starting
of the machine.
SUSPENSION
The complete machine is suspended by heavy duty three
legs on universal oscillating steel pins with heavy
steel springs and spherical bearings.
OPTIONAL
FEATURES
-
AC Variable Frequency Drive with Dynamic Braking and
Programmable Logic Controller (PLC) for complete automation.
- High
Speed Models available in 18” and 24” Basket dia.
- Gas
Tight Construction
Advantages
of 4 Point Mounting
- No
need for elaborate foundation / civil work
- Can
be easily relocated.
- Almost
negligible maintenance cost for suspension / mounting
system
- Level
of vibration much lower.
- Can
be easily mounted on upper floors.
Technical
Specifications for 3 point Pendulum Suspension Hydro
Extractor:
| Model |
Unit |
24" |
36" |
48" |
60" |
72" |
Basket Diameter
|
mm |
610 |
915 |
1219 |
1524 |
1830 |
Basket height
|
mm |
355 |
406 |
457 |
571 |
635 |
| Working capacity under Lip |
Liters |
70 |
160 |
260 |
525 |
1000 |
| Basket Load |
Kgs |
30 |
55 |
110 |
225 |
400 |
| Max. Basket Revolution |
rpm |
1200 |
1000 |
900 |
800 |
550 |
| Motor Power |
KW / HP |
3.7 / 5 |
5.5 / 7½ |
8 / 10 |
15 / 20 |
18.5 / 30 |
| Total weight |
Ton |
0.95 |
1.5 |
2.5 |
3.5 |
4.5 |
PLEASE
NOTE:
-
The above capcities are for woolen Blankets. We have
no data regarding capacities in case of difference
fabric, yarn and chemicals which will vary according
to the density of the material.
- We
reserve the right to alter size, weight and design
features.
|
Manual
Top Discharge
Hydro Extractor
3
Point Manual Top Discharge
...............................................
4
Point Manual Top Discharge
|
